ARB Subsystem
ARB commands program the constant-dwell arbitrary waveforms. Constant-dwell waveforms can
have up to 65,535 points assigned to them, with the same dwell time for each point.
[SOURce:]
ARB
:COUNt <value>|INFinity Specifies the number of times the Arb repeats.
:CURRent
:CDWell
[:LEVel] <value>{,<value>}|<Block> Specifies the level of each point in the Arb.
:DWELl <value> Specifies the dwell time of each point in the Arb.
:POINts? Returns the number of points in the Arb.
:FUNCtion
:TYPE CURRent|VOLTage Specifies either a voltage or current Arb.
:TERMinate
:LAST 0|OFF|1|ON Selects the output setting after the Arb ends.
:VOLTage
:CDWell
[:LEVel] <value>{,<value>}|<Block> Specifies the level of each point in the Arb.
:DWELl <value> Specifies the dwell time of each point in the Arb.
:POINts? Returns the number of points in the Arb.
[SOURce:]ARB:COUNt <value>|MIN|MAX|INFinity
[SOURce:]ARB:COUNt? [MIN|MAX]
Specifies the number of times the Arb repeats. Use the INFinity parameter to repeat the Arb
continuously.
Parameter Typical Return
1 – 256, *RST 1 <count>
Programs a repeatcount of 10: ARB:COUN10
[SOURce:]ARB:CURRent:CDWell[:LEVel] <value>{,<value>}|<Block>
[SOURce:]ARB:CURRent:CDWell[:LEVel]?
[SOURce:]ARB:VOLTage:CDWell[:LEVel] <value>{,<value>}|<Block>
[SOURce:]ARB:VOLTage:CDWell[:LEVel]?
Specifies the level of each point in the Arb. Values are specified in either amperes or volts. The
minimum and maximum values depend on the ratings of the unit.
6 SCPI Programming Reference
211 Keysight N6900/N7900 Series Operating and Service Guide
