CURRent Subsystem
Current commands program the output current of the instrument.
[SOURce:]
CURRent
[:LEVel]
[:IMMediate]
[:AMPLitude] <value> Sets the output current when in current priority mode
:TRIGgered
[:AMPLitude] <value> Sets the triggered output current
:LIMit
[:POSitive]
[:IMMediate]
[:AMPLitude] <value> Sets the current limit when in voltage priority mode.
:NEGative
[:IMMediate]
[:AMPLitude] <value> Sets the current limit when in voltage priority mode.
:MODE FIXed|STEP|LIST|ARB Sets the transient mode.
:PROTection
:DELay
[:TIME] <value> Sets the over-current protection delay.
:STARt SCHange|CCTRans Specifies what starts the over-current protection delay timer.
:STATe 0|OFF|1|ON Enables or disables the over-current protection.
:SHARing
[:STATe] 0|OFF|1|ON Enables or disables current sharing on paralleled units.
:SLEW
[:IMMediate] <value>|INFinity Sets the current slew rate.
:MAXimum 0|OFF|1|ON Enables or disables the maximum slew rate override.
[SOURce:]CURRent[:LEVel][:IMMediate][:AMPLitude] <value>|MIN|MAX
[SOURce:]CURRent[:LEVel][:IMMediate][:AMPLitude]? [MIN|MAX]
[SOURce:]CURRent[:LEVel]:TRIGgered[:AMPLitude] <value>|MIN|MAX
[SOURce:]CURRent[:LEVel]:TRIGgered[:AMPLitude]? [MIN|MAX]
Sets the immediate or triggered current level when the output is operating in current priority mode.
The triggered level is a stored value that is transferred to the output when an output Step is
triggered.Units are in amperes.The maximum value depends on the current rating of the unit. The
minimum value is the most negative value.
Parameter Typical Return
-10.2% to 102% of rating, *RST 0
With power dissipator: up to -102% to 102% of rating
<current level>
Sets the positive current limitto 2 A: CURR:LIM 2
Keysight N6900/N7900 Series Operating and Service Guide 218
6 SCPI Programming Reference
