N6954A/N6974A Test Record Report Number ______ Date__________
Test Description Model Min. Specs Results Max. Specs
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
Both
Both
Both
Both
+ 68 mV
Vout – 12 mV
79.964 V
Vout – 36 mV
_______
_______
_______
_______
+ 92 mV
Vout + 12 mV
80.036 V
Vout + 36 mV
CV Load Effect: Both – 2 mV _______ + 2 mV
CV Ripple and Noise
peak-to-peak:
rms:
Both
Both
N/A
N/A
_______
_______
+ 9 mV
+ 1 mV
Transient response @ 100 µs: Both – 200 mV _______ + 200 mV
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
N6954A
N6974A
N6954A
N6974A
N6954A
N6974A
N6954A
N6974A
– 4 mA
– 8 mA
Iout – 4 mA
Iout – 8 mA
12.4835 A
24.967 A
Iout – 0.0165 A
Iout – 0.033 A
_______
_______
_______
_______
_______
_______
_______
_______
+ 4 mA
+ 8 mA
Iout + 4 mA
Iout + 8 mA
12.5165 A
25.033 A
Iout + 0.0165 A
Iout + 0.033 A
CC Load Effect: N6954A
N6974A
– 0.8 mA
– 1.5 mA
_______
_______
+ 0.8 mA
+ 1.5 mA
Current Sink Tests
10% of current rating:
100% of current rating:
N6954A
N6974A
N6954A
N6974A
– 1.2553 A
– 2.5105 A
– 12.5165 A
– 25.033 A
_______
_______
_______
_______
– 1.2488 A
– 2.4895 A
– 12.4835 A
– 24.967 A
N6954A Settings N6974A Settings
Voltage Programming & Readback Min:
Voltage Programming & Readback High:
CV Load Effect, CV Ripple and Noise:
Transient Response:
Current Programming & Readback Min:
Current Programming & Readback High:
CC Load Effect:
10% of current rating (Isink):
100% of current rating (Isink):
Voltage priority: 80 mV, 12.5 A
Voltage priority: 80 V, 12.5 A
Voltage priority: 80 V, 12.5 A
Voltage priority: 80 V, 6.25 A to 12.5 A
Current priority: 80 V, 0 A
Current priority: 80 V, 12.5 A
Current priority: 80 V, 12.5 A
Current priority: 80 V, - 1.25 A
External supply: 80 V, 1.375 A
Current priority: 80 V, - 12.5 A
External supply: 80 V, 13.75 A
Voltage priority: 80 mV, 25 A
Voltage priority: 80 V, 25 A
Voltage priority: 80 V, 25 A
Voltage priority: 80 V, 12.5 A to 25 A
Current priority: 80 V, 0 A
Current priority: 80 V, 25 A
Current priority: 80 V, 25 A
Current priority: 80 V, - 2.5 A
External supply: 80 V, 2.75 A
Current priority: 80 V, - 25 A
External supply: 80 V, 27.5 A
7 Verification and Calibration
