VOLTage Subsystem
Voltage commands program the output voltage of the instrument.
[SOURce:]
VOLTage
[:LEVel]
[:IMMediate]
[:AMPLitude] <value> Sets the output voltage when in voltage priority mode.
:TRIGgered
[:AMPLitude] <value> Sets the triggered output voltage.
:BWIDth LOW|HIGH1 Sets the voltage bandwidth.(for backward compatibility)
:LEVel 0|1, <value> Sets the programming pole frequency.
:RANGe 0|1 Sets the voltage bandwidth.
:LIMit
[:POSitive]
[:IMMediate]
[:AMPLitude] <value> Sets the voltage limit when in current priority mode.
:MODE FIXed|STEP|LIST|ARB Sets the transient mode.
:PROTection
[:LEVel] <value> Sets the over-voltage protection level.
:RESistance
[:LEVel]
[:IMMediate]
[:AMPLitude] <value> Sets the output resistance when in voltage priority mode.
:STATe 0|OFF|1|ON Enables or disables resistance programming in voltage pri-
ority mode.
:SLEW
[:IMMediate] <value>|INFinity Sets the voltage slew rate.
:MAXimum 0|OFF|1|ON Enables or disables the maximum slew rate override.
[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude] <value>|MIN|MAX
[SOURce:]VOLTage[:LEVel][:IMMediate][:AMPLitude]? [MIN|MAX]
[SOURce:]VOLTage[:LEVel]:TRIGgered[:AMPLitude] <value>|MIN|MAX
[SOURce:]VOLTage[:LEVel]:TRIGgered[:AMPLitude]? [MIN|MAX]
Sets the immediate or triggered voltage level when the output is operating in voltage priority mode.
The triggered level is the value that is transferred to the output when an output Step is triggered.
Units are in volts. The maximum value depends on the voltage rating of the unit.
Parameter Typical Return
0.1% to 102% of rating, *RST 0.1% of rating <voltage level>
Sets the output voltage to 20 V: VOLT20
Keysight N6900/N7900 Series Operating and Service Guide 280
6 SCPI Programming Reference
