Front Panel Menu Reference SCPI Command
Select Transient\Step
Select either the Trig Voltage or the Trig Current box and
enter the step value.
In Voltage priority mode:
VOLT:TRIG <value>
In Current priority mode:
CURR:TRIG <value>
Designate the "master" unit (Unit 1) as the source of the Step trigger signal.
Front Panel Menu Reference SCPI Command
Select Transient\Step
Check Enable Trigger Output.
Select the Step function as the trigger source:
STEP:TOUT ON
Program the Digital Trigger Pins
Configure pin 1 as the transient trigger source on all units.
Front Panel Menu Reference SCPI Command
Select Transient\TrigSource
Select Pin 1 from the dropdown list.
Select the transient trigger source:
TRIG:TRAN:SOUR PIN1
Configure pin 1 as the trigger output for the “master”(Unit 1).
The master unit will provide the trigger signal to synchronize all units.
Front Panel Menu Reference SCPI Command
Select System\IO\DigPort\Pins
Select Pin 1, then selectthe Trig Out function. Keep the
polarity setto Positive.
Select the trigger output function:
DIG:PIN1:FUNC TOUT
Select the pin polarity:
DIG:PIN1:POL POS
Configure pin 1 as the trigger input for the remaining paralleled units (Unit 2, 3, etc.)
These units will receive the trigger signal from the master unit.
Front Panel Menu Reference SCPI Command
Select System\IO\DigPort\Pins
Select Pin 1, then selectthe Trig In function. Keep the
polarity setto Positive.
Select the trigger input function:
DIG:PIN1:FUNC TINP
Select the pin polarity:
DIG:PIN1:POL POS
Enable the Output and Trigger Additional Output Changes
Enable the outputs. All outputs will be set to the initial voltage and current values.
Keysight N6900/N7900 Series Operating and Service Guide 171
4 Using the Advanced Power System
