Front Panel Menu Reference SCPI Command
Select System\Admin\Cal\Misc\CurrShar.
Check thatthe short is connected and selectNext.
CAL:CURR:SHAR
Step 3. Select the first calibration point. Measure the voltage across the sharing connector and enter
the data.
Front Panel Menu Reference SCPI Command
Display shows: “Enter P1 measured data”. Enter the data from
the external DVM. This should be about -1 volt. Press Enter
when done.Press Back to finish.
CAL:LEV P1
*OPC?
CAL:DATA <data>
Step 4. After the calibration completes, disconnect the voltmeter and short.
Resistance Bottom-Out Calibration
This procedure calibrates the minimum voltage that can be achieved while sinking current.
Step 1. Connect an external power supply to the + and - output terminals (see Cal Setup E).
Step 2. Set the external supply as follows: Voltage setting = (0.9 V + 0.08 * rated output voltage of the
power supply) volts. The voltage must be within 10% of this value. Current limit = (0.95 * rated output
current of the power supply) amps. The current limit must be within 2% of this value.
Step 3. Select the resistance bottom-out calibration. Calibration takes approximately 5 seconds.
Front Panel Menu Reference SCPI Command
Select System\Admin\Cal\Misc\ResBout. Check thatthe
power supply is connected and select Next.
CAL:RES:BOUT
*OPC?
Step 4. After the calibration completes, disconnect the power supply.
Enter a Calibration Date
Front Panel Menu Reference SCPI Command
Select System\Admin\Cal\Date.
Enter the calibration date in the Date field. If desired, you can
enter alphanumeric data in this field.
CAL:DATE "<date>"
Save Calibration and Log Out
Front Panel Menu Reference SCPI Command
Select System\Admin\Cal\Save. Select Save.
Select System\Admin\Logout
To save calibration data: CAL:SAVE
To exit calibration mode: CAL:STAT OFF
Keysight N6900/N7900 Series Operating and Service Guide 321
7 Verification and Calibration
