9 Programming the Instrument
9.4 Status Register System & STATus Subsystem
Command
:STATus:QUEStionable:INTegrity:SIGNal:ENABle?
Example
:STAT:QUES:INT:SIGN:ENAB 4
Burst Not Found will be reported to the Integrity Summary of the Status Questionable register
Preset 32767
Min 0
Max 32767
Status Bits/OPC
dependencies
Sequential command
Questionable Integrity Signal Event Query
Returns the decimal value of the sum of the bits in the Questionable Integrity Signal
Event register.
NOTE
The register requires that the associated PTRansition or NTRansition filters be
set before a condition register bit can set a bit in the event register. The data in
this register is latched until it is queried. Once queried, the register is cleared.
Remote Command
:STATus:QUEStionable:INTegrity:SIGNal[:EVENt]?
Example
:STAT:QUES:INT:SIGN?
Preset 0
Status Bits/OPC depend-
encies
Sequential command
Questionable Integrity Signal Negative Transition
Determines which bits in the "Questionable Integrity Signal Condition" on page
1147 register will set the corresponding bit in the "Questionable Integrity Signal
Event Query" on page 1148 register when the condition register bit has a negative
transition (1 to 0).
The variable <integer> is the sum of the decimal values of the bits that you want to
enable.
Remote
Command
:STATus:QUEStionable:INTegrity:SIGNal:NTRansition <integer>
:STATus:QUEStionable:INTegrity:SIGNal:NTRansition?
Example
:STAT:QUES:INT:SIGN:NTR 4
Burst not found being cleared will be reported to the Integrity Summary of the Status Questionable
register
Preset 0
IQ Analyzer Mode User's &Programmer's Reference 1148
