KIP 5000 - Section 5 KIP AutoCAD Driver

5-1
Section 5
KIP AutoCAD Driver
Page
1.0 Overview and Features 5- 2
2.0 Connection 5- 4
2.1 Options 5- 4
2.2 KIP Request Link – Advanced Features 5- 4
3.0 Installation 5- 5
4.0 Configuration 5- 8
4.1 Media 5- 8
4.2 Graphics 5- 9
4.3 Custom Properties 5- 9
5.0 Custom Settings 5- 12
5.1 Printer Connection 5- 13
5.1.1 Link to Request Software 5- 13
5.1.2 Put Pen & Media into File 5- 13
5.1.3 Machine 5- 13
5.1.4 Status 5- 13
5.2 Plot Identification 5- 14
5.2.1 Requester/User Name 5- 14
5.2.2 Job Number 5- 14
5.2.3 Description 5- 14
5.2.4 Stamp 5- 14
5.3 Printer Connection 5- 15
5.3.1 Type 5- 15
5.3.2 Fold 5- 15
5.3.3 Save Paper 5- 15
5.3.4 Header 5- 15
5.4 Raster Image Control 5- 16
5.4.1 Gamma 5- 16
5.4.2 Density 5- 16
5.4.3 Raster photo Mode 5- 16
5.5 Color Merge Control 5- 17
5.6 Adjustments 5- 17
6.0 Appendix 5- 18
6.1 Accounting Features - Variables 5- 18
