Section 1 Basic Printer Functions
1-33
8-3) Rotate the green knob as shown by the arrow and feed the leading edge of the media
between the Feeding Rollers
8-4) Close the Roll Deck.
8-5) Press the Initial Cut Key on the User Interface (UI) to cut the leading edge.
Remove the cut leading edge.
Front
Rear
Roll 1
Roll 2
Roll 3
Roll 4
Knob
Knob
NOTE
When you load the media, rotate the Paper Feeding Roller Knob.
Do not feed the media
too much because the leading edge may come out from the gap. If you close the Roll
Deck while the leading edge is sticking out of the gap, the roll media will fold and printing
will be unavailable.
To Next Page
