Section 1 Basic Printer Functions
1-58
4. 1. 1 Paper Mis-feed in Roll Deck Section
(J-01, J-02, J-03, J-04)
When the Paper Mis-feed occurs in the Roll Deck, the Operation Panel indicates a “J-01”, “J-02”,
“J-03” or “J-04”.
J-01 : Mis-feed in Roll 1
J-02 : Mis-feed in Roll 2
J-03 : Mis-feed in Roll 3
J-04 : Mis-feed in Roll 4
Ex.) The paper mis-feed occurs in Roll 1.
Clear the Paper Mis-feed using the following procedure:
1) Open the Roll Deck, and then rewind the roll onto the media core.
MENU ENTER TEST
TONER REMAIN IMAGE DENSITY
job
Roll 3
Roll 4
Roll 1
Roll 2
J-01
J-02
J-03
J-04
Front Rear
