Kostal INVEOR Drive Controller - Page 107

Parameters
Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN 107
34.227 Init time Unit: s
Relationship
to parameter:
34.226
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 100
def.: 0.25
For synchronous motors only.
Here the time during which the start up current 34.226 is stamped can be set.
34.228 –
34.230
Start-up procedure Unit: integer
Relationship
to parameter:
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 Own value
(to be entered!)
max.: 1
def.: 0
For synchronous motors only.
By changing the start-up procedure to “Controlled”, higher starting torques
can be achieved.
0 = regulated, the drive controller directly to the control after
the stamping phase.
1 = controlled, after the stamping phase the rotation field is increased by the
control with start ramp
34.229 up to start frequency 34.230, then switched to the controller.
