5.3.3 Motor potentiometer
This mode must be selected in parameter 1.130.
The function can be used as a target value source for frequency mode and for the PID process
controller.
The motor potentiometer can be used to gradually increase / decrease the target value
(PID/frequency). Use parameters 2.150 to 2.154 for this purpose.
2.150 MOP digital Input Unit: integer
Relationship
to parameter:
1.130
4.030
4.050
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 8
def.: 3
Selection of the source for increasing and reducing the target value
0 = digital input 1 + / digital input 2 -
7 = INVEOR soft PLC
8 = foil keypad (key 1 - / key 2 +)
2.151 MOP step range Unit: %
Relationship
to parameter:
1.020
1.021
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 Own value
(to be entered!)
max.: 100
def.: 1
Increments at which the target value changes per keystroke.
2.152 MOP step time Unit: s
Relationship
to parameter:
Parameter
manual:
P. xy
Transfer status:
2
min.: 0.02 Own value
(to be entered!)
max.: 1000
def.: 0.04
Indicates the time during which the target value is totalled with a permanent
signal.
