Optional accessories
124 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
This chapter contains brief descriptions of the following optional accessories:
 Adapter plates
 MMI handheld controller including connection cable RJ9 on M12 plug
 Brake resistors
9.1 Adapter plates
9.1.1 Motor adapter plates
A standard motor adapter plate is available for each INVEOR α size.
Download the 3D files (.stp) for INVEOR and adapter plates from
www.kostal-industrie-elektrik.com.
INVEOR size
M α
Output 0.25 kW to 0.75 kW
Designation
ADP Mα MOT
0000 A-000 1
Art. no. 10117052
The customer needs to drill the four holes for mounting the standard adapter plate on the motor.
Below are technical drawings showing the possible locations of the holes for each of the respective
sizes.
INFORMATION
The system integrator is responsible for whether the connection between the motor and
adapter plate satisfies the mechanical requirements of the application.
Because the motor does not form part of the scope of supply of the drive controller, the system
integrator must ensure the following when assembling the drive controller on the motor.
• Actual dimensions of the attachment interface
• Blind hole depth, diameter and thread type of attachment points
IMPORTANT INFORMATION
KOSTAL Industrie Elektrik GmbH assumes no liability for the connection between the motor
and INVEOR
!
