Installation
44 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
Relay X6
Designation
Assignment
COM
Centre contact relay
NO
Normally open contact relay
NC
Normally closed contact
For technical data on power connections, see page 35
3.4.4 Placing cooling elements on adapter plate
Fig.: 17 Placing cooling elements on adapter plate
1. Plug motor plug (1) onto motor terminal X411 (2).
