Installation
40 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
3.4.2 Power connection
Fig.: 15 Mains connection cable connection
1. Screw cable screw connection (1) into cooling elements (2) (M
A
= 3 Nm).
2. Guide mains connection cable (3) through cable screw connection (1) into cooling elements
(2).
Fix mains connection cable (3) by tightening (M
A
= 3 Nm) rear section of cable screw
connection (1).
