Optional accessories
126 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
9.1.3 Wall adapter plates (standard)
A standard wall adapter plate is available for each INVEOR α size.
Download the 3D files for INVEOR and adapter plates from
www.kostal-industrie-elektrik.com.
Four holes for mounting the adapter plate are present.
INVEOR size
M α
Output 0.25 kW to 0.75 kW
Designation
ADP Mα WDM
0000 A-000 1
Art. no. 10117051
Fig.: 37 Hole pattern for size α standard wall adapter plate
