Kostal INVEOR Drive Controller - Performance Parameters; Motor Data

Parameters
98 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
6.070 /
6.071
Target / nominal value deviation Unit: %
Relationsh
ip to
parameter:
4.150
4.190
4.230
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 % / 0 sec. Own value
(to be entered!)
max.: 100 % / 32767 sec.
def.: 0 % / 0 sec.
A target / actual value comparison can be undertaken with this function.
The result is output via the field bus status word or a digital output.
Parameter 6.070 can be used to define the tolerance range of the target value.
Parameter 6.071 can be used to set the time for which the actual value has to be outside
the tolerance range before the output is reset.
Example:
Operating mode = PID control
PID target value = 50 %
6.070 = 10 %
6.071 = 1 sec.
As soon as the actual value is between 40 % and 60 %, the output is set.
If the actual value is outside 40 % to 60 % for 1 sec., the output is reset.
5.5 Performance parameters
5.5.1 Motor data
33.001 Type of motor Unit: integer
Relationship
to parameter:
33.010
Parameter
manual:
P. xy
Transfer status:
1
min.:
1 Own value
(to be entered!)
max.: 2
def.: 1
Selection of type of motor.
1 = asynchronous motor
2 = synchronous motor
The parameters are shown depending on the type of motor selected.
The type of control (parameter 34.010) must also be selected.
