80 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
5.3.5 Analogue input
For analogue input 1
4.020 AI1 input type Unit: integer
Relationship
to parameter:
Parameter
manual:
P. xy
Transfer status:
2
min.: 1 Own value
(to be entered!)
max.: 2
def.: 1
Function of analogue input 1.
1 = voltage input
2 = current input
4.021 AI1 standard. Low Unit: %
Relationship
to parameter:
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 Own value
(to be entered!)
max.: 100
def.: 0
Specifies the minimum value of the analogue input as a percentage of the
range
Example:
0…10 V and/or 0…20 mA = 0 %...100 %
2…10 V and/or 4…20 mA = 20 %...100 %
4.022 AI1 standard. High Unit: %
Relationship
to parameter:
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 Own value
(to be entered!)
max.: 100
def.: 100
Specifies the maximum value of the analogue input as a percentage of the
range.
Example:
0…10 V and/or 0…20 mA = 0 %...100 %
2…10 V and/or 4…20 mA = 20 %...100 %
