Installation
28 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
3.1 Safety instructions for installation
DANGER!
Risk of death due to revolving mechanical parts!
Death or serious injury!
De-energise drive controller and secure it against being restarted.
Only allow appropriately qualified staff to install the drive controller.
Only use staff who are trained in mounting, installation, commissioning and handling.
Always ground the device in accordance with DIN EN 61140; VDE 0140, NEC and
other relevant standards.
Mains connections must be hardwired.
CAUTION!
Risk of burns from hot surfaces!
Serious burns to the skin from hot surfaces!
Allow the drive controller's cooling elements to cool sufficiently.
3.2 Recommended preliminary fuses / line protection
INVEOR Alpha Size α
1 x 230 V AC
Nominal motor
rating
up to 0.75 kW
Mains current
7.3 A
Mains current
150%
(overload
60 s)
10.95 A
Line circuit
breaker -
recommendatio
n
C 16
Characteristics C = line circuit breaker
tripping between 6 – 10 times In
The cross-section of the supply line must be designed according to the
transfer category and maximum permitted current. The contractor
commissioning the device must ensure protection for the power line.
