84 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
5.3.7 Digital output
For digital input 1
4.150 DO1 function Unit: integer
Relationship
to parameter:
4.151
4.152
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 Own value
(to be entered!)
max.: 51
def.: 0
Selection of the process variable to which the output should switch.
0
1
2
3
4
5
8
9
10
11
12
13
14
17
18
19
20
21
22
23
24
25
26
28
29
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
=
Not assigned / INVEOR soft PLC
Intermediate circuit voltage
Grid voltage
Motor voltage
Motor current
Actual frequency value
IGBT temperature
Inner temperature
Error (NO)
Error inverted (NC)
Limit steps enable
Digital input 1
Digital input 2
Ready for operation (mains supply on, no HW enable, motor
stationary)
Ready (mains supply on, HW enable set, motor stationary)
Operation (mains supply on, HW enable set, motor running)
Ready for operation + Ready
Ready for operation + Ready + Operation
Ready + Operation
Motor rating
Torque
Field bus
Analogue input 1 (V 3.60 and higher)
PID target value (V 3.60 and higher)
PID actual value (V 3.60 and higher)
Table continues on next page
