Parameters
Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN 85
4.150 DO1 function Unit: integer
Relationship
to parameter:
4.151
4.152
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 51
def.: 0
Selection of the process variable to which the output should switch.
30
31
32
33
34
35
36
37
38
39
50
51
=
=
=
=
=
=
=
=
=
=
=
=
Continuation of table
STO channel 1 (V 03.70 and higher)
STO channel 2 (V 03.70 and higher)
Target frequency value after ramp (V 03.70 and higher)
Target frequency value (V 03.70 and higher)
Actual speed value (V 03.70 and higher)
Actual frequency value sum (V 03.70 and higher)
Torque sum (V 03.70 and higher)
Target frequency value after ramp sum (V 03.70 and higher)
Target frequency value sum (V 03.70 and higher)
Actual speed value sum (V 03.70 and higher)
Motor current limit enabled (V 03.70 and higher)
Nominal-actual comparison (para. 6.070 – 6.071)
(V 03.70 and higher)
4.151 DO1 on Unit:
Relationship
to parameter:
4.150
Parameter
manual:
P. xy
Transfer status:
2
min.:
- 32767 Own value
(to be entered!)
max.: 32767
def.: 0
If the set process variable exceeds the switch-on limit, the output is set to 1.
4.152 DO1 off Unit:
Relationship
to parameter:
4.150
Parameter
manual:
P. xy
Transfer status:
2
min.:
- 32767 Own value
(to be entered!)
max.: 32767
def.: 0
If the set process variable exceeds the switch-off limit, the output is again set
to 0.
