Disassembly and disposal
116 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
This chapter contains the following:
A description of how to disassemble the drive controller
Information on correct disposal
7.1 Drive controller disassembly
CAUTION!
Risk of burns from hot surfaces!
Serious burns to the skin from hot surfaces!
Allow the drive controller's cooling elements to cool sufficiently
.
DANGER!
Risk of death due to electrical shock!
Death or serious injury!
De-energise drive controller and secure it against being restarted.
If damaged parts or components need replacing, only ever replace with
original parts.
Danger due to electrical shock and discharge. Wait two minutes (discharge
time of the capacitors) after shut-down.
1. Release four retaining bolts of cooling elements.
2. Carefully lift cooling elements off adapter plate.
3. Remove all cables.
4. Remove the drive controller.
5. Release the adapter plate's retaining bolts.
6. Remove the adapter plate.
7.2 Information on correct disposal
Dispose of drive controller, packaging and replaced parts in accordance with the regulations of the
country in which the drive controller has been installed.
The drive controller may not be disposed of with household waste.
