Parameters
Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN 105
34.110 Slip trimmer Unit:
Relationship
to parameter:
33.034
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 1.5
def.: 1
Only for asynchronous motors.
This parameter can be used to optimise or deactivate slippage compensation.
0 = disable (performance as on the grid)
1 = compensation for slippage.
Example: 4 pole asynchronous motor at 1410 rpm, target frequency 50 Hz
Motor idling
0 = approx. 1500 rpm
1 = 1500 rpm
Motor at nominal point
0 = 1410 rpm
1 = 1500 rpm
50 Hz is always displayed as the actual frequency.
34.130 Voltage control reserve Unit:
Relationship
to parameter:
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 Own value
(to be entered!)
max.: 2
def.: 0.95
Only for asynchronous motors.
This parameter can be used to adjust voltage output.
5.5.5 Quadratic characteristic curve
34.120 Quadratic characteristic curve Unit: integer
Relationship
to parameter:
34.121
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 1
def.: 0
Only for asynchronous motors.
The quadratic characteristic curve function can be activated here.
0 = disable
1 = enable
