Parameters
Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN 79
3.074 PID nominal value max. Unit: %
Relationship
to parameter:
3.073
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 100
def.: 100
(V 03.70 and higher)
The PID nominal value can be limited using 2 parameters.
Example: 0 -10 V nominal value potentiometer
Read Min PID nominal value = 20 %
Read Max PID nominal value = 80 % (3.073)
Nominal value at < 2 V = 0 %
Nominal value at 2 V – 8 V = 20 % - 80 %
Nominal value at > 8 V = 80 %
3.080 PID minimum frequency 2 Unit: Hz
Relationship
to parameter:
1.020
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 Own value
(to be entered!)
max.: 400
def.: 0
(V 03.80 and higher)
The minimum frequency is calculated depending on the PID target value
Example:
1.020 minimum frequency = 10 Hz
3.080 PID minimum frequency 2 = 20 Hz
Minimum frequency when PID target value is 0 % = 10 Hz
Minimum frequency when PID target value is 50 % = 15 Hz
Minimum frequency when PID target value is 100 % = 20 Hz
