Parameters
76 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
3.052 PID-P amplification factor Unit: s
Relationship
to parameter:
1.100
1.130
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 100
def.: 0
Differential share of PID controller amplification factor
3.060 PID actual value Unit: integer
Relationship
to parameter:
1.100
1.130
3.061
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 3
def.: 0
Selection of the input source from which the actual value for the PID process
controller is imported:
0 = analogue input 1
2 = INVEOR soft PLC
3 = field bus (fixed customer-specific input variable 2) (V 03.72 and higher)
3.061 PID inverted Unit: integer
Relationship
to parameter:
3.060
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 Own value
(to be entered!)
max.: 1
def.: 0
The actual value source (parameter 3.060) is inverted
0 = disable
1 = enable
3.062 to 3.068 PID fixed target values Unit: %
Relationship
to parameter:
1.130
3.069
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 Own value
(to be entered!)
max.: 100
def.: 0
The PID fixed target values which are to be issued depending on the switching
patterns at the digital inputs 1 – 3 specified in parameter 3.069 (has to be
selected in parameter 1.130).
