Parameters
68 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
1.100 Operating mode Unit: integer
Relationship
to parameter:
1.130
1.131
2.051 to 2.057
3.050 to 3.071
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 3
def.: 0
Selecting the operating mode
Following software enabling (1.131) and hardware enabling, the drive controller
runs as follows:
0 = frequency setting mode, with the target value of the selected target value
source (1.130)
1 = PID process controller, with the target value of the PID process controller
(3.050 – 3.071),
2 = fixed frequencies, with the frequencies defined in parameters
2.051 – 2.057.
3 = selection via INVEOR soft PLC
1.130 Target value source Unit: integer
Relationship
to parameter:
3.062 to 3.069
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 10
def.: 0
Determines the source from which the target value is to be read.
0 = internal potentiometer
1 = analogue input 1
3 = MMI/PC
4 = SAS / Modbus (V 03.80 and higher)
6 = motor potentiometer
8 = PID fixed target values (3.062 to 3.069)
9 = field bus
10 = INVEOR soft PLC
