Parameters
Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN 67
1.054 Ramp selection Unit: integer
Relationship
to parameter:
1.050 - 1.053
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 9
def.: 0
Selection of used ramp pair
0 = deceleration 1 (1.050) / acceleration 1 (1.051)
1 = deceleration 2 (1.052) / acceleration 2 (1.053)
2 = digital input 1 (false = ramp pair 1 / true = ramp pair 2)
3 = digital input 2 (false = ramp pair 1 / true = ramp pair 2)
6 = customer PLC
7 = analogue input 1 (must be selected in parameter 4.030) (V 03.70 and
higher)
9 = virtual output (4.230) (V 03.70 and higher)
1.088 Rapid stop Unit: s
Relationship
to parameter:
Parameter
manual:
P. xy
Transfer status:
2
min.: 0.1 Own value
(to be entered!)
max.: 1000
def.: 10
Only for the variant with functional safety
The rapid stop parameter prescribes the time that the inverter requires to
brake to 0 Hz from the max. speed (1.021).
If the set rapid stop time cannot be achieved, the fastest possible deceleration
time is implemented.
