Parameters
78 Operating manual for INVEOR α | DOC01539818 - 0004 | 2017-01 | V2.0 EN
3.072 PID dry run time Unit: s
Relationship
to parameter:
Parameter
manual:
P. xy
Transfer status:
2
min.: 0 Own value
(to be entered!)
max.: 32767
def.: 0
(V 03.70 and higher)
After this set time, if the PID actual value has not reached at least 5 % and
the controller is running at the max. limit, the INVEOR switches off with error
no. 16 PID dry run.
3.073 PID nominal value min Unit: %
Relationship
to parameter:
3.074
Parameter
manual:
P. xy
Transfer status:
2
min.:
0 Own value
(to be entered!)
max.: 100
def.: 0
(V 03.70 and higher)
The PID nominal value can be limited using 2 parameters.
Example: 0 -10 V nominal value potentiometer
Read Min PID nominal value = 20 %
Read Max PID nominal value = 80 % (3.074)
Nominal value at < 2 V = 20 %
Nominal value at 2 V – 8 V = 20 % - 80 %
Nominal value at > 8 V = 80 %
