01/FORK, TRIPLE CLAMP 12
5.3Adjusting spring preload of fork
Info
The spring preload defines the initial situation of the spring process of the fork.
An optimally adjusted spring preload is adapted to the rider's weight and ensures a compromise between easy handling and
stability.
700348-01
– Turn the adjusting spindles clockwise until they stop.
Info
The adjusting spindles are located at the top end of the fork legs.
Make the same adjustment on both fork legs.
– Turn back counterclockwise the number of turns corresponding to the fork type.
Guideline
Spring preload - Preload Adjuster
Comfort 5 turns
Standard 5 turns
Sport 3 turns
full payload 3 turns
Info
Turn clockwise to increase preload, turn counterclockwise to reduce spring
preload.
Changing the spring preload has no influence on the rebound damping
although the adjusting screws turn during the adjustment work. However,
you should also adjust the rebound damping when you alter the spring
preload.
5.4bleeding fork legs
– Lean the motorcycle on the side stand.
700259-01
– Remove bleeder screws briefly.
Any excess pressure escapes from the interior of the fork.
– Mount and tighten bleeder screws.
Info
Perform this action on both fork legs.
