TECHNICAL DATA - ENGINE TIGHTENING TORQUES 166

31TECHNICAL DATA -ENG INETIGHTE NINGTORQU ES

Hose clip, intake flange M4 1.5 Nm (1.11 lbf ft) –

Screw, gear sensor M5 3 Nm (2.2 lbf ft)

Loctite

243™

Screw, pulse generator M5 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, bearing retainer M5 6 Nm (4.4 lbf ft)

Loctite

243™

Remaining engine screws M5 6 Nm (4.4 lbf ft) –

Jet 140 M6x0.75 4 Nm (3 lbf ft)

Loctite

243™

Oil jet M6x0.75 4 Nm (3 lbf ft)

Loctite

243™

Oil jet for clutch lubrication M6x0.75 4 Nm (3 lbf ft) –

Nut, cylinder head M6 10 Nm (7.4 lbf ft) –

Screw, locking lever M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, freewheel holder M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, freewheel ring M6 13 Nm (9.6 lbf ft)

Loctite

648™

Screw, generator cover M6 10 Nm (7.4 lbf ft) –

Stud, chain shaft M6 8 Nm (5.9 lbf ft) –

Screw, coolant connection on cylinder

head

M6 10 Nm (7.4 lbf ft) –

Screw, clutch cover M6 10 Nm (7.4 lbf ft) –

Screw, clutch spring M6 12 Nm (8.9 lbf ft)

Loctite

243™

Screw, engine housing M6x60 10 Nm (7.4 lbf ft) –

Screw, engine housing M6x80 10 Nm (7.4 lbf ft) –

Screw, engine housing M6x90 10 Nm (7.4 lbf ft) –

Screw, camshaft bearing support M6 10 Nm (7.4 lbf ft) –

Screw, oil pump cover M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shift drum locating M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shift lever M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, starter motor M6 10 Nm (7.4 lbf ft) –

Screw, stator clamp M6 10 Nm (7.4 lbf ft)

Loctite

243™

Plug, vacuum connection M6 5 Nm (3.7 lbf ft)

Loctite

243™

Screw, valve cover M6 10 Nm (7.4 lbf ft) –

Screw, water pump cover M6 10 Nm (7.4 lbf ft) –

Screw, water pump wheel M6 10 Nm (7.4 lbf ft)

Loctite

243™

Remaining engine screws M6 10 Nm (7.4 lbf ft) –

Vacuum connection M6 5 Nm (3.7 lbf ft)

Loctite

243™

Stud, exhaust flange M8 10 Nm (7.4 lbf ft) –

Screw, timing chain guide rail M8 15 Nm (11.1 lbf ft)

Loctite

243™

Plug, crankshaft retainer M8 15 Nm (11.1 lbf ft) –

Screw, engine housing M8 18 Nm (13.3 lbf ft) –

Screw, engine console M8 20 Nm (14.8 lbf ft)

Loctite

243™

Screw, camshaft bearing support M8 Step 1

10 Nm (7.4 lbf ft)

Step 2

18 Nm (13.3 lbf ft)

–

Screw, camshaft bearing support M8 Step 1

8.5 Nm (6.27 lbf ft)

Step 2

14.5 Nm (10.7 lbf ft)

Only applies when using:

Hex key bit

(61229025000)

( p. 200)

Screw, timing chain tensioning rail M8 15 Nm (11.1 lbf ft)

Loctite

243™

Screw, heat exchanger M8 15 Nm (11.1 lbf ft) –

Oil pressure sensor M10x1 10 Nm (7.4 lbf ft) –

Screw, timing chain tensioner release M10x1 10 Nm (7.4 lbf ft) –

Plug, clutch lubrication M10x1 15 Nm (11.1 lbf ft) –
