11/WIRING HARNESS, BATTERY 49
1511/WIRING HARNESS, BATTERY
15.1Removing the battery
Warning
Risk of injury Battery acid and battery gases cause serious chemical burns.
– Keep batteries out of the reach of children.
– Wear suitable protective clothing and goggles.
– Avoid contact with battery acid and battery gases.
– Keep the battery away from sparks or open fire. Charge only in well-ventilated rooms.
– In the event of skin contact, rinse with large amounts of water. If battery acid gets in the eyes, rinse with water for at least
15 minutes and contact a physician.
– Switch off all power-consuming components and switch off the engine.
– Remove the seat. ( p. 32)
700276-10
– Disconnect the negative (minus) cable of the battery.
700277-10
– Remove the plus pole cover.
– Disconnect the positive (plus) cable of the battery.
700278-01
– Remove screws .
– Removing the securing bracket .
– Pull the battery upwards out of the battery rack.
Info
Never operate the motorcycle with a discharged battery or without a battery.
In both cases, electrical components and safety equipment can be dam-
aged. The vehicle is then no longer safe to ride.
15.2Installing the battery
700279-01
– Position the battery in the battery rack.
Info
The poles of the battery must face the rear of the vehicle.
– Position the bracket .
