06/AIR FILTER 28
1006/AIR FILTER
10.1Removing the air filter
Note
Engine failure Unfiltered intake air has a negative effect on the service life of the engine.
– Never ride the vehicle without an air filter since dust and dirt can get into the engine and result in increased wear.
– Dismount the fuel tank. ( p. 32)
200496-10
– Remove screws .
– Slide back clamp . Pull off the engine breather hose and take off the clamp.
– Take off the filter box top.
Info
Watch out for the engine breather hose.
200497-10
– Remove air filter .
– Clean the air filter box.
10.2Installing the air filter
200497-11
– Position air filter .
200496-11
– Position the filter box top with the engine breather hose. Mount clamp  with the
engine breather hose.
– Tighten screws .
– Install the fuel tank. ( p. 33)
10.3Removing the filter box bottom
– Remove the air filter. ( p. 28)
