TECHNICAL DATA - TOLERANCE, WEAR LIMITS OF ENGINE 164
30TECHNICAL DATA -TOL ERANCE,WE ARLIMITS OFENGINE
Camshaft - cam height
Intake 39.34… 39.44 mm (1.5488… 1.5528 in)
Exhaust 38.59… 38.69 mm (1.5193… 1.5232 in)
Camshaft - bearing pin 23.960… 23.980 mm (0.94331… 0.94409 in)
Camshaft bearing - radial clearance
New condition 0.020… 0.061 mm (0.00079… 0.0024 in)
Wear limit 0.09 mm (0.0035 in)
Valve guide - diameter
New condition 6.004… 6.016 mm (0.23638… 0.23685 in)
Wear limit 6.050 mm (0.23819 in)
Valve - sealing seat width
Intake: New condition 1.0 mm (0.039 in)
Intake: Wear limit 1.7 mm (0.067 in)
Exhaust: New condition 1.0 mm (0.039 in)
Exhaust: Wear limit 2.0 mm (0.079 in)
Valve - run-out
On the valve stem ≤ 0.05 mm (≤ 0.002 in)
On the valve plate: New condition ≤ 0.016 mm (≤ 0.00063 in)
On the valve plate: Wear limit ≤ 0.030 mm (≤ 0.00118 in)
Valve - valve stem diameter
Exhaust 5.893… 5.970 mm (0.23201… 0.23504 in)
Intake 5.965… 5.980 mm (0.23484… 0.23543 in)
Valve spring - length
New condition 42.0 mm (1.654 in)
Wear limit 41.2 mm (1.622 in)
Cylinder head - bearing hole of camshaft 24.000… 24.021 mm (0.94488… 0.94571 in)
Cylinder/cylinder head - sealing area distortion ≤ 0.05 mm (≤ 0.002 in)
Cylinder - bore diameter
Size I 103.000… 103.012 mm (4.05511… 4.05558 in)
Size II 103.013… 103.025 mm (4.05562… 4.05609 in)
Piston - diameter
Size I 102.955… 102.985 mm (4.05334… 4.05452 in)
Size II 102.965… 102.995 mm (4.05373… 4.05491 in)
Piston/cylinder - mounting clearance
New condition 0.015… 0.057 mm (0.00059… 0.00224 in)
Wear limit 0.150 mm (0.00591 in)
Piston - piston pin hole diameter 20.010… 20.020 mm (0.78779… 0.78819 in)
Piston ring
Width, first ring (L-ring) 0.870… 0.895 mm (0.03425… 0.03524 in)
Width, first ring (L-ring) 1.170… 1.195 mm (0.04606… 0.04705 in)
Width, second ring (tapered compression piston ring) 1.220… 1.250 mm (0.04803… 0.04921 in)
Width, oil scraper ring 2.497… 2.500 mm (0.09831… 0.09843 in)
Piston ring - groove clearance
First ring (L-ring) ≤ 0.105 mm (≤ 0.00413 in)
Second ring (tapered compression piston ring) ≤ 0.210 mm (≤ 0.00827 in)
Oil scraper ring ≤ 0.180 mm (≤ 0.00709 in)
Piston ring end gap ≤ 0.5 mm (≤ 0.02 in)
Piston pin - diameter 19.995… 20.004 mm (0.7872… 0.78756 in)
Connecting rod - diameter of upper conrod eye 20.000… 20.013 mm (0.7874… 0.78791 in)
Connecting rod - axial clearance of lower conrod bearing
New condition 0.10… 0.25 mm (0.0039… 0.0098 in)
Wear limit 0.40 mm (0.0157 in)
