30/DISASSEMBLING THE ENGINE 88
19.33Removing the primary gear
200412-10
– Loosen nut of primary gear and remove it together with the washer.
Info
Left-handed thread!
Make sure that the crankshaft is blocked.
200413-10
– Remove the primary gear with special tool , and .
Extractor (78029033100) ( p. 202)
Pressure piece (61229018000) ( p. 200)
Arms for extractor 78029033100 (61229017000) ( p. 200)
19.34Removing the force pump
200414-10
– Remove lock washer and washer . Take off oil pump gear .
200415-10
– Remove pin and washer .
– Remove screws .
– Remove the oil pump cover.
