June 2018
Legrand PDU User Guide 61
Menu command Function
Alerts
Indicates all alerted sensors, if any. See Alerts (on page 61).
PDU
Shows the internal beeper's state, and, if it is on, the reason for turning
on.
If your Legrand PDU has multiple inlets, this menu item also shows the
total active power and total active energy.
See PDU (on page 62).
Inlet I1
Shows the inlet I1's information. See Inlet (on page 63).
OCPs
Shows a list of overcurrent protector information. See OCPs (on page
64).
Only Legrand
PDU models with overcurrent protectors have this menu
item.
Outlets
This menu command is available on Legrand Switched PDUs only.
Shows each outlet's information.
If your Legrand PDU supports outlet-switching, you can turn on, off or
power cycle an outlet.
See Outlets (on page 65).
Peripherals
Shows the information of connected Raritan environmental sensors or
actuators, such as the temperature sensor.
You can turn on or off a connected actuator with this command.
See Peripherals (on page 67).
Device Info
Shows the device information of Legrand PDU, such as IP and MAC
address. See Device Info (on page 70).
Note: To return to the automatic mode, press . See Automatic and Manual Modes (on page 58).
Alerts
The "Alerts" menu command shows a list of the following alerted sensors, including both internal and
external sensors.
Any numeric sensor that enters the warning or critical range if the thresholds have been enabled
State sensors that enter the alarmed state
Any tripped circuit breakers or blown fuses
Tip: The same information is available in the web interface's Dashboard. See Dashboard - Alerted Sensors
(on page 91).
If there are no alerted sensors, the LCD display shows the message "No Alerts."
To view alerted sensors:
1. Press
or to select "Alerts" in the Main Menu, and press .
2. Alerted sensors, if any, are highlighted in either red or yellow. For color definitions, see Yellow- or
Red-Highlighted Sensors (on page 120).
