Chapter 17:
Bill of Materials
CHAPTER 17: BILL OF MATERIALS
804-575: DPS-475/575 Unit Overview
Designation Description DPS Part Number
3PINCBLE CABLE ASSY 3” 78211-003&48049 773-771
AC_CORD POWER CORD BELDEN 17254-EUROPE 773-254 [Europe]
AC_CORD POWER CORD AC 120V 773-505 [North America]
BLOWER FAN BFB0712H 12VDC 0.36A 701-575
BOTSCREW SCREW 440X3/16SS UNDERCUT PH. 751-052
CABLETIE CABLE TIE MOUNTING DEVICE 762-138
CHASSIS MTL DPS575 CHASSIS 741-978
CORCONN CONN CORCOM 3CFS1 LINE FILTER 722-300
DCN_PCB ASSY REAR PNL DPS575 843-572
DISPCBL2 CABLE 20 PIN RIBBON 575 774-752
ENC_ASSY ASSY SHAFT ENCODER DPS-475/575 843-575
FAN_12V FAN MICRO 701-485
FAN_SCRW SCREW 4-40 X 1 PH ZN PHILL 751-054
FANBRKT MTL DPS575 FAN BRACKET SET 741-980
FANCOVER MTL FAN COVER PLATE 741-988
FISH_570 FISHPAPER DPS-575 VIDEO BOARD 764-570
FISHPTOP FISH PAPER 290/575 TOP COVER 764-097
FLTRLENS PLASTIC FILTER/LENS FOR VFD MD 740-022
FOAM PACK FOAM STABILIZER 7 3/4X17 742-040
FOAM2 PACKING FOAM-ENDS (SET of 4) 742-203
FRNT_BRD ASSY FRONT PNL DPS575 843-571
FRNTPNL1 MTL DPS575 F/PANEL INNER 741-984
FRNTPNL2 MTL DPS575 F/P OUTER 741-984A
GROMET GROMET RUBBER 1/2” DIA 754-575
HANDLES METAL DIE CAST HANDLES -465 741-006
HEATSHRK HEATSHRINK TUBING 3/16” 764-144
JACKSCRW JACK SCREW 621250104115 762-142
KNOB KNOBS C210-0X RE AN 733-024
KNOBCAP KNOB CAP T210-OX RE AN 733-025
LANCABLE CABLE FIREWIRE/6PIN MOLEX 774-140
LBL_FCC LABEL FCC 704-017
LBL_VOLT LABEL-CAUTION RISK OF ELEC SHO 704-137
LBL_WIRE LABEL DPS-575/475 PS wiring 704-012
LEXANLBL LABEL 475/575 FP LEXAN 704-575
LGEBOX PACKING BOX DPS-LARGE STUDIO 742-038
MAIN_PCB ASSY MAIN BOARD DPS575 843-570
MTLCOVER MTL DPS575 COVER 741-979
NUT_BNC BRASS NP PANEL HEX NUT NK 753-025
NUT_HNDL 6-32 K-LOCK NUT ZINC 753-011
NUT_PSU 6-32 K-LOCK NUT ZINC 753-011
NUTS_FAN NUT HEX 6-32 #4 BLANK 753-050
PCB_SCRW SCREW 4-40 X 1/4 PH ZN PH 751-010
POLYBAG PACKING POLY BAG 22” X 22” 742-045
147
