For parameters which have a numerical range of values, the display will show both a
numeric and a visual representation of the range, and the control knob can be used to
set the new value.
Note that adjustments affect the output immediately as the knob is turned.
When setting parameters with a numerical range of values, you can switch the control
knob between Fine and Coarse adjustment mode. When you first enter the parameter
adjustment screen, the control knob is in Fine mode. Pressing the Enter button
switches to Coarse adjustment mode, and the Enter button lights up. This allows you
to make large adjustments more quickly. Pressing the Enter button again returns the
control knob to Fine mode.
For example, when setting the a parameter, the control knob may adjust the value in
increments of 0.02 while in Fine Mode, and 0.50 in Coarse mode.
Pressing the Default button will reset the configuration parameter to its default values.
The Default button will be lit whenever the current value of the parameter is
equivalent to the default value, whether you reached this value by pressing the
Default button, or by scrolling to it with the control knob.
Press the Exit button to accept your new value, and return to the previous menu or
sub-menu.
Menu Tree
This section provides an overview of the menu structure of the DPS-475/575, and
where specific menu selections are located. Detailed explanations of the menus and
options appear in subsequent chapters.
Main Menu
Video Setup
Luma Gain
Black Level
Chroma Gain
Hue Phase
Color Balance - Cb
Color Balance - Cr
Video AGC
AGC Bias
Input H-Position
Input Y/C Delay
Sync Mode
3D Comb Decoder
3D Chroma Motion Bias
Comb Decoder
DigiDuplex Mode
Self Setup to Bars
More Video Settings
Hot Switch
Hot Switch Delay
Trouble Slide
Trouble File
Freeze Mode
24
DPS-475/575 Service Manual
