Chapter 4:
Menu Overview and Feature Cross-Reference
CHAPTER 4: MENU OVERVIEW AND
F
EATURE CROSS-REFERENCE
Menu Controls
All options and parameters for the DPS-475/575 are accessed through configuration
menus, which appear on the display panel. The menus of the DPS-475 and DPS-575
are organized into eight main functional areas:
• Video Setup
• Audio Setup (on audio-equipped units only)
• Keyer Setup
• Noise Reduction
• DV Control (on units with DV I/O Module only)
• Timing Setup
• TSG/Image Grabbing
• System Config
Moving Through the Menus
Selecting and using any of the menu and sub-menu options follows the same general
procedure.
1. With the Idle Screen displayed, press the Enter button. (If the Idle Screen is not
displayed, press Exit repeatedly until it is.) The display panel will show the Main
Menu options.
2. Use the control knob to select one of the sub-menus listed in the main menu. To
do so, scroll through the list using the control knob, until the desired sub-menu is
highlighted. Press the Enter button to enter the sub-menu.
3. Use the control knob and Enter button to choose and activate the option you
want. If there are further sub-menus, use the procedure in step 2 to select
between them, and to select the option you wish to change.
Pressing the Exit button while in a menu or sub-menu will return you to the previous
sub-menu, or if you are at the main menu, to the Idle Screen.
Changing Parameters
Once you have selected the option you wish to change, use the control knob to set the
new value for the parameter. When setting parameters that have discrete value options
(such as selecting Field, Frame, or Strobe mode), the control knob will cycle through
the valid settings.
23
