Audio Cable (Standard)
The following are the cable pinouts for the standard AES/EBU (DB-25M) audio
cable, part number 774-755, included with the DPS-475/575AV.
Pin Number on the DB-25M Connection Type Description
1NC
2NC
3NC
4NC
5NC
6NC
7NC
8NC
9NC
10 NC
11 NC
12 NC
13 NC
14 BNC – Shield AES2 Out (–)
15 NC
16 BNC – Center AES2 Out (+)
17 BNC – Shield AES2 In (–)
18 NC
19 BNC – Center AES2 In (+)
20 BNC – Shield AES1 Out (–)
21 NC
22 BNC – Center AES1 Out (+)
23 BNC – Shield AES1 In (–)
24 NC
25 BNC – Center AES1 In (+)
222
DPS-475/575 Service Manual
