Chapter 12:
Menus: System Config
CHAPTER 12: MENUS: SYSTEM CONFIG
The System Config menu is used for configuration of the DPS-475/575. Settings in
the System Config menu are generally used for initial setup of the unit, not in regular
operation.
Line Standard (525/625) [DPS-575 Only]
Selects between 525-line (NTSC) and 625-line (PAL) standards.
Current
Displays the line standard currently in use:
525 lines Using 525-line standard, user-specified.
625 lines Using 625-line standard, user-specified.
Auto (525) Using 525-line standard, auto-detected.
Auto (625) Using 625-line standard, auto-detected
Switch to 525
This option is only available when the DPS-575 is currently running in 625-line mode
(either user-specified or automatically detected). Selecting this option disables line
standard auto-switching, and switches the unit to 525-line mode.
Switch to 625
This option is only available when the DPS-575 is currently running in 525-line mode
(either user-specified or automatically detected). Selecting this option disables line
standard auto-switching, and switches the unit to 625-line mode.
Disable Autoswitch / Switch to Auto
Enables or disables line standard auto-switching. When line standard auto-switching
is enabled, the unit will automatically switch line standards based on the current input
signal, and the Current field (described earlier in this section) will report Auto (XXX),
where XXX is the detected line standard.
When line standard auto-switching is disabled, the unit will remain in the currently
selected line standard, regardless of the video input.
Misc. Setup
Internal Temp
Reports the internal temperature of the unit, in Celsius.
73
