Chapter 17:
Bill of Materials
804-575AV: DPS-475/575AV Unit Overview
Designation Description DPS Part Number
3PINCBLE CABLE ASSY 3” 78211-003&48049 773-771
AC_CORD POWER CORD BELDEN 17254-EUROPE 773-254 [Europe]
AC_CORD POWER CORD AC 120V 773-505 [North America]
AUDCABLE CABLE AUDIO BREAKOUT CABLE 774-755
AUDIOPCB ASSY AUDIO BOARD DPS575 843-573
BOTSCREW SCREW 440X3/16SS UNDERCUT PH. 751-052
CABLETIE CABLE TIE MOUNTING DEVICE 762-138
DCN_PCB ASSY REAR PNL DPS575 843-572
DISPCBL2 CABLE 20 PIN RIBBON 575 774-752
ENC_ASSY ASSY SHAFT ENCODER DPS-475/575 843-575
FAN_SCRW SCREW 4-40 X 1 PH ZN PHILL 751-054
FANCOVER MTL FAN COVER PLATE 741-988
FISH_570 FISHPAPER DPS-575 VIDEO BOARD 764-570
FISH_573 FISHPAPER DPS-575 AUDIO BOARD 764-573
FISHPTOP FISH PAPER 290/575 TOP COVER 764-097
FOAM PACK FOAM STABILIZER 7 3/4X17 742-040
FOAM2 PACKING FOAM-ENDS (SET of 4) 742-203
FRNT_BRD ASSY FRONT PNL DPS575 843-571
FRNTPNL1 MTL DPS575 F/PANEL INNER 741-984
FRNTPNL2 MTL DPS475 F/P OUTER 741-984B
GROMET GROMET RUBBER 1/2” DIA 754-575
HEATSHRK HEATSHRINK TUBING 3/16” 764-144
JACKSCRW JACK SCREW 621250104115 762-142
LANCABLE CABLE FIREWIRE/6PIN MOLEX 774-140
LGEBOX PACKING BOX DPS-LARGE STUDIO 742-038
MAIN_PCB ASSY MAIN BOARD DPS575 843-570
NUT_BNC BRASS NP PANEL HEX NUT NK 753-025
NUT_HNDL 6-32 K-LOCK NUT ZINC 753-011
NUT_PSU 6-32 K-LOCK NUT ZINC 753-011
NUTS_FAN NUT HEX 6-32 #4 BLANK 753-050
PCB_SCRW SCREW 4-40 X 1/4 PH ZN PH 751-010
POLYBAG PACKING POLY BAG 22” X 22” 742-045
PSUCABLE CABLE 570 PWR SUP TO MAINBRD 774-750
PWRHARNS CABLE 570 AC TO PWR SUP 774-751
RCKGUIDE MTL DPS575 R/GUIDE 2SET 741-983
REARFILL MTL FILLER DPS575 SET OF 2 741-986
SCREW_RG SCREW 4-40 X 3/8 PH ZN PHIL 751-007
SCRW_AUD SCREW 4-40 X 7/16 PH ZN PHILL 751-057
SCRW_BCK SCREW 4-40 X 1/4 PH ZN PH 751-010
SCRW_BLO SCREW 4-40 X 1 PH ZN PHILL 751-054
SCRW_CVR SCREW 4/40 X 3/16 FLAT UNDER 751-107
SCRW_HDL SCREW 6-32 X 5/16 PAN PHI MS 751-021
SCRW_PSB SCREW 6-32 X 1/4 PH ZN PHILL 751-029
SCRWFANC SCREW 4-40 X 1/4 PH ZN PH 751-010
SCRWFRNT SCREW 4-40 X 5/16 PH ZN PHIL 751-006
SHIELD MTL DPS575 AUDIO CARRIER PLT 741-982
SHRINK HEAT SHRINK TUBE 1/8” DIA. 764-122
STANDOFF STANDOFF 4 X 40 4505-440B12RAF 762-170
STNDOFDV STANDOFF 4-40 X 5/16 M/F 762-575
STNDOFFM 4-40 X 1/4 M/F 3/16 HEX SS 762-2300
TERM_AUD CONN 1840463 PLUG COMBICON 722-184
149
