Leitch DPS-475 - 843-573: Audio Synchronizer Module

843-573: Audio Synchronizer Module
Designation Description DPS Part Number
AC1 CAP SMT 0.01UF CER 0805 345-104
AC3 CAP SMT 0.01UF CER 0805 345-104
AC4 CAP SMT 0.01UF CER 0805 345-104
AC5 CAP SMT 0.01UF CER 0805 345-104
AC6 CAP SMT 47UF TANT 7343 357-476
AC7 CAP SMT 0.1UF CER 0805 345-105
AC8 CAP SMT 47UF TANT 7343 357-476
AC9 CAP SMT 0.1UF CER 0805 345-105
AC10 CAP SMT 47UF TANT 7343 357-476
AC11 CAP SMT 0.1UF CER 0805 345-105
AC14 CAP SMT 47UF TANT 7343 357-476
AC15 CAP SMT 0.1UF CER 0805 345-105
AC16 CAP SMT 0.01UF CER 0805 345-104
AC18 CAP SMT 0.01UF CER 0805 345-104
AD1 DIODE SMT MMBD914LT1 354-914
AD2 DIODE SMT MMBD914LT1 354-914
AD3 DIODE SMT MMBD914LT1 354-914
AD4 DIODE SMT MMBD914LT1 354-914
AD5 DIODE SMT MMBD914LT1 354-914
AD6 DIODE SMT MMBD914LT1 354-914
AD7 DIODE SMT MMBD914LT1 354-914
AD8 DIODE SMT MMBD914LT1 354-914
AG1 HEADER 2 PIN OF 761-141 761-152
AG2 HEADER 2 PIN OF 761-141 761-152
AG3 HEADER 2 PIN OF 761-141 761-152
AJ1 HEADER 6 PIN OF 761-141 761-146
AK1 RELAY AGN200A12 651-200
AK2 RELAY AGN200A12 651-200
AK3 RELAY AGN200A12 651-200
AK4 RELAY AGN200A12 651-200
AK5 RELAY AGN200A12 651-200
AK6 RELAY AGN200A12 651-200
AK7 RELAY AGN200A12 651-200
AK8 RELAY AGN200A12 651-200
AK9 RELAY AGN200A12 651-200
AK10 RELAY AGN200A12 651-200
AK11 RELAY AGN200A12 651-200
AK12 RELAY AGN200A12 651-200
AK13 RELAY AGN200A12 651-200
AK14 RELAY AGN200A12 651-200
AK15 RELAY AGN200A12 651-200
AK16 RELAY AGN200A12 651-200
AK17 RELAY AGN200A12 651-200
AK18 RELAY AGN200A12 651-200
AL1 FERRITE BLM41P600S SMT 1806 331-416
AL2 FERRITE BLM41P600S SMT 1806 331-416
178
DPS-475/575 Service Manual
