AGC Bias adjustment screen; each subsequent GPI pulse will cycle through the
allowed adjustment values.
When set to Voice-Over, the unit’s audio voice-over mode (see Chapter 6, “Menus:
Audio Setup”) will be activated by a GPI signal. When the GPI signal is first
received, program audio begins fading down, then voice-over mixing begins. Voice-
over mixing continues while the GPI signal is present. Voice-over mixing is stopped
and program audio begins ramping back up upon release of the GPI trigger. This GPI
option is similar to activating and de-activating the Voice-Over option of the Global
Audio Config sub-menu.
GPI input can be contact closure to ground or TTL signal (0 to 5 volts max.).
GPO Function
Selects the functionality of the GPI Output/Audio Delay Pulse connection of the
Multi I/O breakout cable.
Valid Settings: Audio Pulse, Bad Input, Keyer Active,
SDI Input, Voice-Over
Default Setting: Audio Pulse
When set to Audio Pulse, a pulse will be sent on this output at a regular interval
(approximately every two frames).
When set to Bad Input, a signal will be continuously output when no valid video
signal is present on the currently selected video input.
When set to Keyer Active, a signal will be continuously output when the unit’s linear
keyer is active.
When set to SDI Input, a signal will be continuously output when the unit’s input
video selection is set to SDI.
When set to Voice-Over, a signal will be continuously output while the audio voice-
over mixing is active. This signal will NOT be output during the fade-down and
ramp-up of program audio that preceed and follow, respectively, voice-over mixing.
“Active” output is TTL compatible, 5 volts / 20 mA max.
Genlock Changes
Enables or disables the ability of the operator to make changes to the genlock timing
settings found in the Timing Setup menu.
Valid Settings: Enabled, Disabled
Default Setting: Enabled
When this setting is disabled, changes cannot be made to the unit’s genlock timing
options.
VFD Brightness
Adjusts the brightness level of the Vacuum Fluorescent Display (VFD) display panel
on the front of the unit.
Valid Range: 1 to 15
Default Setting: 7
Note that higher values will shorten the lifespan of the display panel.
