Appendix H
APPENDIX H: CABLE PINOUTS
Video Cable
The following are the cable pinouts for the Multi I/O Connector (DB-15M) video
cable, part number 774-753.
Pin Number on the DB-15M Connection Type Description
1 Gnd Ground
2 BNC Aux Blue
3 Gnd Ground
4 S-Video S-Video Chroma (C)
5 RCA GPI In 1
6 BNC Aux Red
7 Gnd Ground
8 BNC Aux Sync/Comp. Out
9 Gnd Ground
10 BNC Audio Delay/GPI Out
11 BNC Aux Green
12 Gnd Ground
13 S-Video S-Video Luma (Y)
14 Gnd Ground
15 RCA GPI In 2
221
