Appendix A
APPENDIX A: SPECIFICATIONS
Video Specifications
Inputs:
Composite Video (BNC) ...........1Vp-p, 75Ω
Serial Digital SDI (BNC) ..........75Ω, Auto EQ to 300 M (With
Reclocked and Buffered BNC Output)
Component Analog Video (BNC):
Y .......................................1Vp-p, 75Ω
R-Y, B-Y ..........................0.7Vp-p, 75Ω
S-Video (4P Mini-DIN):
Y ......................................1Vp-p, 75Ω
C (Burst Level) ................286 mV (NTSC), 300 mV (PAL)
DV I/O Option (6-pin Molex)...IEEE-1394
Genlock Ref. (BNC Loop) ........1Vp-p, 75Ω
Outputs:
Composite Video (BNC x2) ......1Vp-p, 75Ω
Serial Digital SDI (BNC x2) .....75Ω
Component Analog Video (BNC):
Y .......................................1Vp-p, 75Ω
R-Y, B-Y ..........................0.7Vp-p, 75Ω
S-Video (4P Mini-DIN)*:
Y .......................................1Vp-p, 75Ω
C (Burst Level) ...............286 mV (NTSC), 300 mV (PAL)
RGB/RGBS Analog Video (BNC)*
+
:
RGB..................................1Vp-p, 75Ω
Sync..................................300 mV or 8Vp-p (selectable)
DV I/O Option (6-pin Molex)...IEEE-1394
Signal Processing:
ADC/DAC and Composite
Encoding/Decoding ...................12-bit
Component YUV Pipeline.........10-bit
Synchronizing Range................. Infinite
Frequency Response:
Synchronizer Mode....................+/– 0.25 dB (0 - 5.5 MHz)
–1 dB (5.5 - 5.75 MHz)
TBC Mode .................................–3 dB (0 - 4.2 MHz, Notch at 3.58/
4.43 MHz)
Signal to Noise:
TSG/SDI Input Modes...............>75 dB Luminance Weighted
Synchronizer Mode....................>70 dB Luminance Weighted
TBC Mode .................................>60 dB Luminance Weighted
Differential Phase..............................<1° (Modulated Ramp)
Differential Gain................................<1% (Modulated Ramp)
K-Factor (2T) ....................................<0.5% (2T Pulse)
