Leitch DPS-475 - 843-574: Animated Logo Option Assembly; 843-575: Shaft Encoder Assembly

843-574: Animated Logo Option Assembly
Designation Description DPS Part Number
ACN1 CONN SFM-140-L2-S-D-LC 722-048
AR2 RES SMT 0R 5% 0805 342-000
AR4 RES SMT 0R 5% 0805 342-000
AU1 IC AT49BV1604-12TC 16MB FLASH 330-160
AU2 IC AT49BV1604-12TC 16MB FLASH 330-160
EXT_574 EXT ASSY FLASH EXPANSION CARD 843-574EX
PCB PCB DPS-575 FLASH EXPANSION 743-574
ZC1 CAP SMT 0.1UF CER 0805 345-105
ZC2 CAP SMT 0.1UF CER 0805 345-105
ZC3 CAP SMT 0.1UF CER 0805 345-105
ZC4 CAP SMT 0.1UF CER 0805 345-105
ZC5 CAP SMT 0.1UF CER 0805 345-105
ZC6 CAP SMT 0.1UF CER 0805 345-105
ZC7 CAP SMT 0.1UF CER 0805 345-105
ZC8 CAP SMT 0.1UF CER 0805 345-105
ZC9 CAP SMT 0.1UF CER 0805 345-105
ZC10 CAP SMT 0.1UF CER 0805 345-105
843-575: Shaft Encoder Assembly
Designation Description DPS Part Number
ENCODER CONTROL DIGITAL ENCODER FT PNL 411-224
J1 CONN DUPONT 69167-103 722-001
PCB PCB ENCODER 475/575 743-575
188
DPS-475/575 Service Manual
