Chapter 17:
Bill of Materials
843-572: Rear Panel Assembly
Designation Description DPS Part Number
AC1 CAP SMT 0.1UF CER 0805 345-105
AC2 CAP SMT 0.1UF CER 0805 345-105
AJ1 CONN R/A9F 626-009-262-032EDAC 722-441
AJ2 CONN.LOW PROFILE AMP#413879-1 722-369
AJ3 RIBBON CABLE 20 PIN DPS 285 774-309
AU1 IC SN75124D/SO16 337-124
AU2 IC SN75121D/SO16 337-121
EXT_572 EXT ASSY REAR PNL DPS575 843-572EX
PCB_572 PCB DPS-575 REAR PANEL BRD 743-572
177
