Enter key to select the desired file. The file will be loaded, and you will be returned
to the Keyer Setup menu. This does not activate the keyer; it simply loads the file into
memory.
These images could have been uploaded to the unit from a PC or grabbed from video
from the TSG/Image Grabbing menu. See Appendix D, “The Uploader Software” or
Appendix F, “Ethernet Control”, for instructions on uploading new images to the unit,
and Chapter 11, “Menus: TSG/Image Grabbing,” for instructions on grabbing images
from video.
Settings
Selects a stored keyer settings profile. Selecting the Settings option displays a list of
stored keyer settings profiles. The profile to be loaded is selected by scrolling through
the list with the control knob, and pressing the Enter key to select the desired profile.
In addition to profiles previously stored by the user, the factory default keyer settings
can be recalled.
Related Settings: Change Settings
Change Settings
The Change Settings sub-menu provides configuration options determining how a key
will be transitioned and displayed.
Shift X
Adjusts the horizontal position of the key over the incoming video. If the key is active
(currently being displayed), it will be repositioned in real-time on the live outputs as
this value is adjusted.
Valid Range: 0 pels to 718 pels
Default Setting: 0 pels
Shift Y
Adjusts the vertical position of the key over the incoming video. If the key is active
(currently being displayed), it will be repositioned in real-time on the live outputs as
this value is adjusted. Adjustments are in increments of 2.
Valid Range: 0 lines to 486 lines (525-line mode)
0 lines to 572 lines (625-line mode)
Default Setting: 0 lines
Fade In Time
Specifies the duration of the fade-in when a key is transitioned onto the video outputs.
Valid Range: 0 fields to 3600 fields
Default Setting: 60 fields (525-line mode)
50 fields (625-line mode)
Related Settings: Fade In
60
DPS-475/575 Service Manual
