Chapter 17:
Bill of Materials
843-571: Front Panel Assembly
Designation Description DPS Part Number
AC1 CAP SMT 0.1UF CER 0805 345-105
AC2 CAP SMT 10UF TANT 16V 3528 358-106
AD11 DIODE LED T-1 GREEN 104-234
AD11_S SPACER .350 BIVAR 908-350 764-350
AD12 DIODE LED T-1 GREEN 104-234
AD12_S SPACER .350 BIVAR 908-350 764-350
AD13 DIODE LED T-1 GREEN 104-234
AD13_S SPACER .350 BIVAR 908-350 764-350
AD14 DIODE LED T-1 GREEN 104-234
AD14_S SPACER .350 BIVAR 908-350 764-350
AD15 DIODE LED T-1 GREEN 104-234
AD15_S SPACER .350 BIVAR 908-350 764-350
AD16 DIODE LED T-1 YELLOW 104-235
AD16_S SPACER .350 BIVAR 908-350 764-350
AD17 DIODE LED T-1 GREEN 104-234
AD17_S SPACER .350 BIVAR 908-350 764-350
AD18 DIODE LED T-1 GREEN 104-234
AD18_S SPACER .350 BIVAR 908-350 764-350
AD21 DIODE LED T-1 GREEN 104-234
AD21_S SPACER .350 BIVAR 908-350 764-350
AD22 DIODE LED T-1 GREEN 104-234
AD22_S SPACER .350 BIVAR 908-350 764-350
AD23 DIODE LED T-1 GREEN 104-234
AD23_S SPACER .350 BIVAR 908-350 764-350
AD24 DIODE LED T-1 YELLOW 104-235
AD24_S SPACER .350 BIVAR 908-350 764-350
AD25 DIODE LED T-1 GREEN 104-234
AD25_S SPACER .350 BIVAR 908-350 764-350
AD26 DIODE LED T-1 GREEN 104-234
AD26_S SPACER .350 BIVAR 908-350 764-350
AD27 DIODE LED T-1 GREEN 104-234
AD27_S SPACER .350 BIVAR 908-350 764-350
AD28 DIODE LED T-1 GREEN 104-234
AD28_S SPACER .350 BIVAR 908-350 764-350
AD31 DIODE LED T-1 GREEN 104-234
AD31_S SPACER .350 BIVAR 908-350 764-350
AD32 DIODE LED T-1 GREEN 104-234
AD32_S SPACER .350 BIVAR 908-350 764-350
AD33 DIODE LED T-1 GREEN 104-234
AD33_S SPACER .350 BIVAR 908-350 764-350
AD34 DIODE LED T-1 RED 104-233
AD34_S SPACER .350 BIVAR 908-350 764-350
AD35 DIODE LED T-1 GREEN 104-234
AD35_S SPACER .350 BIVAR 908-350 764-350
AD36 DIODE LED T-1 GREEN 104-234
AD36_S SPACER .350 BIVAR 908-350 764-350
AD37 DIODE LED T-1 GREEN 104-234
AD37_S SPACER .350 BIVAR 908-350 764-350
AD38 DIODE LED T-1 GREEN 104-234
AD38_S SPACER .350 BIVAR 908-350 764-350
