Chapter 5:
Menus: Video Setup
Chroma Pairing Filter [DPS-575 Only]
Controls the degree of filtering of chroma line pairing artifacts. This option is only
available in 625-line mode [PAL], and is only active when the unit’s TBC is active.
This option has no effect when the unit is in 525-line mode or the TBC is not in use.
Valid Settings: Off, Norm, Max
Default Setting: Norm
The Norm setting should be ideal for most situations, while the Max setting should be
used in cases of severe chroma line pairing artifacting.
NOTE: Users familiar with the DPS-470 (the predecessor to the DPS-475 and DPS-
575) may notice that the SDI Edge Insertion option available on the DPS-470 is not
configurable on the DPS-475/575. SDI Edge Insertion is present in the DPS-475/575,
and is always enabled. “Blanking-to-setup” level transitions are dynamically added by
the unit based on the current input video signal levels. If the input signal lacks setup
(for example, super-black), no unnecessary transitions are generated. If the input
signal has setup, correctly shaped edges are added to conform with RS-170A
specifications (140ns rise time).
43
